Question
A 24 year old builder presents with wrist pain 9 months after a fall onto his outstretched hand. He did not seek treatment at the time. Radiographs show a scaphoid waist fracture with sclerosis and cysts at the fracture margins.
- What is the diagnosis, and why is the scaphoid prone to this problem?
- What investigations would you request?
- Outline your management.
- What happens if this is left untreated?
Answer
Diagnosis
- Established scaphoid waist nonunion
- Retrograde blood supply from dorsal branches of the radial artery entering the distal half
- Intra-articular fracture bathed in synovial fluid, with shear forces across the waist
- Missed or untreated fractures, displacement over 1 mm and proximal pole fractures raise the risk
Investigations
- Scaphoid series radiographs
- CT along the long axis of the scaphoid for displacement, bone loss and humpback deformity (lateral intrascaphoid angle over 35 degrees)
- Lateral radiograph for DISI, with a radiolunate angle over 15 degrees
- MRI, ideally with gadolinium, to assess proximal pole vascularity
Management
- Surgery is indicated in a symptomatic young patient
- Stable nonunion without deformity, headless compression screw with cancellous bone graft
- Humpback deformity, volar approach with a corticocancellous wedge graft to restore length and alignment (Fisk-Fernandez), then screw fixation
- Avascular proximal pole, vascularised graft such as the 1,2 intercompartmental supraretinacular artery graft or a medial femoral condyle free flap
- Cast until CT confirms union, usually at 10 to 12 weeks
Natural history if untreated
- Progressive scaphoid nonunion advanced collapse (SNAC)
- Stage I radial styloid arthritis, stage II scaphocapitate arthritis, stage III capitolunate arthritis
- Salvage with radial styloidectomy, proximal row carpectomy, four corner fusion or total wrist fusion
